PRODUCTS



Technical Parameters







Scope of application
DN150mm-2000mm		 Lens protection
The front of the vehicle is equipped with a detachable anti-collision probe to prevent the nose from being damaged by external forces
Obstacle surmounting ability
The maximum climbing ability can reach more than 35°		 Protection level
IP68
Camera unit
Front and rear 210W dual digital HD cameras, 360° axial and 270° radial rotation		 Drive
Six-wheel drive, powerful horsepower
Zoom
10× optical, 16× digital		 Reeling method
Built-in large-capacity lithium battery, can work continuously for 8-10 hours
Lifting method
Independent electric lift, lens lift 150mm		 Cables
Special tensile cable, standard 120m, customizable
Positioning
With high-precision GPS positioning system, real-time positioning		 Meter
Built-in high-precision electronic encoder, the meter value is continuously displayed on the control unit
illumination
High brightness LED
Main light 8×2W, auxiliary light 8×3.5W		 Anti-rollover design
Superimposed wheel hub and built-in anti-rollover software alarm function, real-time animation simulation to display the crawler's posture inside the pipeline (front and rear tilt angle, left and right tilt angle, lifting platform height)
Defogging, width measurement
With one-button defog function and optional laser width measurement function		 One-click defect tracking
With one-click defect tracking function, quickly locate the defect location







Technical Parameters







Scope of application
DN150mm-2000mm		 Lens protection
The front of the vehicle is equipped with a detachable anti-collision probe to prevent the nose from being damaged by external forces
Obstacle surmounting ability
The maximum climbing ability can reach more than 35°		 Protection level
IP68
Camera unit
Front and rear 210W dual digital HD cameras, 360° axial and 270° radial rotation		 Drive
Six-wheel drive, powerful horsepower
Zoom
10× optical, 16× digital		 Reeling method
Built-in large-capacity lithium battery, can work continuously for 8-10 hours
Lifting method
Independent electric lift, lens lift 150mm		 Cables
Special tensile cable, standard 120m, customizable
Positioning
With high-precision GPS positioning system, real-time positioning		 Meter
Built-in high-precision electronic encoder, the meter value is continuously displayed on the control unit
illumination
High brightness LED
Main light 8×2W, auxiliary light 8×3.5W		 Anti-rollover design
Superimposed wheel hub and built-in anti-rollover software alarm function, real-time animation simulation to display the crawler's posture inside the pipeline (front and rear tilt angle, left and right tilt angle, lifting platform height)
Defogging, width measurement
With one-button defog function and optional laser width measurement function		 One-click defect tracking
With one-click defect tracking function, quickly locate the defect location
