Technical Parameters







Machine size
1800x500x510mm		 Pump discharge capacity
75m3/h
Machine weight
230Kg		 Pump head
35m
Cable length/sewage pump length
50m(standard)or 100m(customized)		 Drive mode
Motor + rubber track
Maximum allowable particles for dredging
15mm		 Walking speed
0.6km/h
System working pressure
Maximum 31Mpa		 Control method
Smart wireless control box
Flow
90L/min		 Optional devices
Dedicated powerful slurry pump, high-definition camera system (including mounting bracket), light source, four-in-one gas detector







Technical Parameters







Machine size
1800x500x510mm		 Pump discharge capacity
75m3/h
Machine weight
230Kg		 Pump head
35m
Cable length/sewage pump length
50m(standard)or 100m(customized)		 Drive mode
Motor + rubber track
Maximum allowable particles for dredging
15mm		 Walking speed
0.6km/h
System working pressure
Maximum 31Mpa		 Control method
Smart wireless control box
Flow
90L/min		 Optional devices
Dedicated powerful slurry pump, high-definition camera system (including mounting bracket), light source, four-in-one gas detector





Application scenario cases

Application scenario cases
